Design Practices Passenger Car Automatic Transmissions, 4th Edition

Since the mid-20th Century, automatic transmissions have benefited drivers by automatically changing gear ratios, freeing the driver from having to shift gears manually. The automatic transmission's primary job is to allow the engine to operate in its speed range while providing a wide range of output (vehicle) speeds automatically. The transmission uses gears to make more effective use of the engine's torque and to keep the engine operating at an appropriate speed.

For nearly half a century, Design Practices: Passenger Car Automatic Transmissions has been the %u201Cgo-to%u201D handbook of design considerations for automatic transmission industry engineers of all levels of experience. This latest 4th edition represents a major overhaul from the prior edition and is arguably the most significant update in its long history. In summary, the authors have put together the most definitive handbook for automatic transmission design practices available today.

Virtually all existing chapters have been updated and improved with the latest state-of-the-art information and many have been significantly expanded with more detail and design consideration updates; most notably for torque converters and start devices, gears/splines/chains, bearings, wet friction, one-way clutch, pumps, seals and gaskets, and controls.

All new chapters have also been added, including state-of-the-art information on:

• Lubrication
• Transmission fluids
• Filtration
• Contamination control

Finally, details about the latest transmission technologies%u2014including dual clutch and continuously variable transmissions%u2014have been added.

Foreword
Preface to the Fourth Edition

Chapter 1 : Transmission Cases and Parking Mechanisms
Chapter 2 : Torque Converters and Start Devices
Chapter 3 : Gears, Splines, and Chains
Chapter 4 : Transmission Shaft Fatigue Design
Chapter 5 : Bearings
Chapter 6 : Friction Clutches
Chapter 7 : One-Way Clutches
Chapter 8 : Automatic Transmission Controls
Chapter 9 : Automatic Transmission Pump Design
Chapter 10 : Seals and Gaskets
Chapter 11 : Transmission Temperature Control and Lubrication
Chapter 12 : ATF and Driveline Fluids
Chapter 13 : Metal Belt Drive Continuously Variable Ratio (CVT) Automatic Transmissions
Chapter 14 : Automatic Transmission and Transaxle Filter Design

Index
