Models for Design: Electrical Calculations for Industrial Plants

Summary

This book instructs the reader on how to size a network’s equipment and address requirements for fast-transient loads (kiloampere loads that last for several minutes). It explores specific calculations used to design equipment for plants. The chapters discuss economic design methods and dynamic-load requirements for electrical equipment. New motor thermal models are developed and power-cable thermal models are also covered. Furthermore, it presents universal plant-load breakdown.

Table of Contents

Chapter 1. Introduction

Part I: Plant Equipment

Chapter 2. Using an Uninterruptable Power Supply to Power a Variable Speed Drive

Chapter 3. Storage Batteries

Part II: One-Line Designs

Chapter 4. The Largest Demand for 13.8 kV Switchgear

Chapter 5. The Minor Influence of the Grid Thevenin Impedance on Plant Faults

Chapter 6. Use of a Three-Winding Step-up Transformer

Part III: Fast Transient Calculations

Chapter 7. Analysis of Power Cables Conducting Fast Transient Loads

Chapter 8. Sizing Power Cables for Fast Transient Loads

Chapter 9. Introduction to Motor Analysis

Chapter 10. Fast Transient Motor Analysis

Chapter 11. Calculation of Motor Temperatures

Chapter 12. Motor Conclusions

Chapter 13. Line Design

Chapter 14. Comparisons of Line Alternative Costs

Chapter 15. Preliminary Cost Estimate
