Fundamentals of Tool Design, 6th Edition

For over 40 years, students, designers, and manufacturing practitioners have used the Fundamentals of Tool Design to gain an in-depth understanding of all the factors that impact tool success. Fully illustrated, readers will find practical design examples, cost analysis calculations, process data, operating parameters, and tips and techniques--all of the concrete knowledge needed to spark innovation and resolve complex tooling challenges.

Among the updates to the Sixth Edition, you'll find updated and expanded tool designer objectives and responsibilities, a designer's guide to machine tools, revised tool material, mechanical definitions and reference tables, expanded broaching examples and concepts, new sections on part location and support, expanded bushing applications, and revised GD&T information to include ASME Y14.5-2009. New appendices provide sources for tool design components, related web sites and search engines, and handy GD&T reference charts. Expanded learning resources include how to use the nine DVDs of the Fundamentals of Tool Design Video series to complement your study. A sample DVD, which includes video clips from the series, is included with the book. Additional review questions at the end of chapters, along with an expanded, standalone Instructor's Guide enhance training and classroom instruction.

Abbreviations
Preface

Chapter 1 : General Tool Design
Chapter 2 : Materials Used for Tooling
Chapter 3 : Cutting Tool Design
Chapter 4 : Workholding Concepts
Chapter 5 : Jig Design
Chapter 6 : Fixture Design
Chapter 7 : Power Presses
Chapter 8 : Die Design and Operation
Chapter 9 : Inspection and Gage Design
Chapter 10 : Tool Design for Joining Processes
Chapter 11 : Modular and Automated Tool Handling
Chapter 12 : Computer Applications in Tool Design
Chapter 13 : Geometric Dimensioning and Tolerancing

Bibliography
Appendix A : Geometric Characteristic Overview of ASME Y14.5-2009
Appendix B : Geometric Tolerancing Reference Charts per ASME Y14.5M-1994
Appendix C : Sources of Tool Design Components
Appendix D : Web Resources
Appendix E : Geometric Characteristic Symbols per ASME Y14.5M-1994
Index
