Geometric Dimensioning and Tolerancing for Mechanical Design, 2nd Edition

AN UP-TO-DATE GUIDE TO GEOMETRIC DIMENSIONING AND TOLERANCING

Written in accordance with the latest revision of the geometric dimensioning and tolerancing (GD&T) stanedard, ASME Y14.5-2009, this book teaches the principles and practical applications of GD&T in an easy-to-understand manner. Geometric Dimensioning and Tolerancing for Mechanical Design, Second Edition, begins the discussion of each control with a definition, and then describes how the control is specified, interpreted, and inspected. Detailed drawings illustrate the topics discussed.

Study questions and problems at the end of each chapter emphasize key concepts and serve as a self-test. Ensure the proper assembly of parts, improve quality, and reduce costs with help from this authoritative resource.

Preface
Acknowledgments

Chapter 1 : Introduction to Geometric Dimensioning and Tolerancing
Chapter 2 : Dimensioning and Tolerancing Fundamentals
Chapter 3 : Symbols, Terms, and Rules
Chapter 4 : Datums
Chapter 5 : Form
Chapter 6 : Orientation
Chapter 7 : Position, General
Chapter 8 : Position, Location
Chapter 9 : Position, Coaxiality
Chapter 10 : Concentricity and Symmetry
Chapter 11 : Runout
Chapter 12 : Profile
Chapter 13 : Graphic Analysis
Chapter 14 : A Strategy for Tolerancing Parts

Appendix
Index
